Product Details:
|
| Frequency Range: | 3500-3750MHz | Gain: | 5dBi |
|---|---|---|---|
| Connector: | SMA Male | Polarization: | Vertical |
| VSWR: | 1.5 | Impedance: | 50 Ohm |
| Length: | 210mm | Maximum Input Power (W): | 50W |
| Color: | Black/ White | Application: | Router Modem |
| High Light: | SMA Male Connector Huawei Router Antenna,5dBi Huawei Router Antenna,SMA Male Connector 5G Router Antenna |
||
MHz 5G antenna SMA male connector high gain Huawei router antenna 5G
Product Details
Item | Specifications | Permissible Tolerance |
Product Information | ||
Place of Origin | Shenzhen, China | / |
Brand Name | MINSTA | / |
Model Number | MST3500M21R | / |
Technical Information | ||
Frequency | 3500-3750Mhz | / |
Gain | 5DBI | ±0.5 DBI |
V.S.W.R | <2.0 | / |
Polarization | Vertical | / |
Bandwidth | 100 | / |
Impedance | 50 Ω | / |
Maximum input power | 50W | / |
Mechanical Information | ||
Material | ABS | / |
Connector | SMA male | / |
Length | 210*20*20mm | ±0.1mm |
Environmental Information | ||
Radiation | Omni-directional | / |
Operating Temperature | -40°C ~ +80°C | / |
Storing temperature | -20°C ~ +50°C | / |
Factory price High gain ipex antenna 7dBi wifi PCB 2.4G 5G 5.8G PCB Antenna with customized cable
Antenna frequency ,Cable length,Cable type ,Connector can be customized as customers' requirement
Packing:Normal plastic bag and carton packing,your OEM packing acceptable
FAQ :
Q: What's your company MOQ?
A: In generally, we will ask at least 100~1000pcs, this we can negotiate.
Q: What's your delivery time?
A: This please check our stock in first, products can be sendtout once receive your payment. Usually, 7-14 days for mass production.
Q: Can your company accept customize?
A: Welcome OEM & ODM.
Q: How do you solve after sale service?
A: One year guarantee. Replacement of defective ones after negotiation.
Q: Can you send a sample for us to develop?
A: Yes, we can. Sample can be sent out once you ask for it, but will ask a sample fee.
