Product Details:
|
| Impedance: | 50 Ω | Frequency Range: | .141" & .085" Semi-rigid Cable: 0-18 GHz Flexible Cables: 0-12.4 GHz |
|---|---|---|---|
| Voltage Rating: | RG-58, 141, 142: 500 Volts Peak RG-174, 188, 316: 375 Volts Peak | Dielectric Withstanding Voltage: | .141" & RG-58 Cables: 1,000 VRMS .085" & RG-316 Cables: 750 VRMS |
| VSWR: | Straight Connector, .141": 1.05 + .005 F (GHz) Straight Connector, .RG-174: 1.15 + .02 F (GHz) Straight Connector, RG-58: 1.15 + .01 F (GHz) Straight Connector, RG-178: 1.20 + .025 F (GHz) | Contact Resistance: | Center Contact: 2.0 MΩ Body: 2.0 MΩ Braid To Body: 0.5 MΩ |
| Insulation Resistance: | 5,000 MΩ | Insertion Loss: | DB Maximum = .06v[f(GHz)] Test Frequency @ 6.0 GHZ |
| RF Leakage: | -90 DB Minimum @ 2.3 GHz | ||
| High Light: | 50 Ohm 90 Degree RF Connector,Right Angle RF Adapter SMA-JWK,90 Degree RF Connector SMA-JWK |
||
50 Ohm Brass SMA Male To SMA Female Right Angle RF Adapter SMA-JWK
|
Electrical |
||
|
Impedance |
50 Ω |
|
|
Frequency Range |
.141" & .085" semi-rigid cable: 0-18 GHz |
|
|
Voltage Rating |
RG-58, 141, 142: 500 volts peak |
|
|
Dielectric Withstanding Voltage |
.141" & RG-58 Cables: 1,000 VRMS |
|
|
VSWR |
Straight connector, .141": 1.05 + .005 f (GHz) |
|
|
Contact Resistance |
Center contact: 2.0 mΩ |
|
|
Insulation Resistance |
5,000 MΩ |
|
|
Insertion Loss |
dB maximum = .06v[f(GHz)] |
|
|
RF Leakage |
-90 dB minimum @ 2.3 GHz |
|
|
Mechanical |
||
|
Mating |
.250-36 threaded coupling |
|
|
Mating Torque |
Minimum: 2 inch pounds (12 N.cm) |
|
|
Connector Durability |
100 matings |
|
|
Material |
||
|
Bodies, Coupling Nuts, Other Metal Parts (except as noted) |
Brass per QQ-B-626 |
|
|
Contacts |
Male: Brass |
|
|
Center Contact Plating |
.000030" minimum gold |
|
|
Plating (Other Metal Parts) |
Standard .000010" gold or nickel plated |
|
|
Insulator |
TFE fluorocarbon |
|
|
Gaskets |
Silicone rubber |
|
|
Crimp Ferrule |
Seamless copper tubing alloy |
|
|
Environmental |
||
|
Temperature Range |
- 65°C to +165°C |
|
|
Thermal Shock |
MIL-STD-202 method 107 (test condition B) except high temperatures @ + 200°C |
|
|
Vibration |
MIL-STD-202 method 204 (test condition D) |
|
|
Shock |
MIL-STD-202 method 213 (test condition I). No discontinuity permitted. |
|
|
Corrosion |
MIL-STD-202 method 101 (test condition B) 5% salt solution |
|
|
Moisture Resistance |
MIL-STD-202 method 106, except step 7b (vibration) omitted, and high humidity measurements do not apply |
|
|
Weatherproofing |
Crimp type: heat shrink tubing |
|
|
Altitude |
MIL-STD-202 method 105 (test condition C), no corona at 70,000 feet. |
|
|
Military Specifications |
||
|
MIL-C-39012 & MIL-C-83517 SMA Specification Sheets |
As applicable |
|
